Weiyuan 0.5-20 Ton Single Beam Gantry Crane
Product Overview
The Weiyuan 0.5-20 Ton Single Beam Gantry Crane is an exceptionally versatile and powerful lifting solution engineered for a wide range of industrial applications. Designed for reliability and efficiency, this crane is perfect for outdoor stockyards, manufacturing workshops, rail terminals, and construction sites where a permanent overhead crane system is not practical. Its robust single-girder A-frame design ensures superior stability and strength, allowing for the safe and efficient handling of materials from 0.5 to 20 tons. This crane combines high performance with a cost-effective design, making it an ideal choice for businesses looking to enhance productivity and streamline their material handling operations.
Product Advantages
Robust A-Frame Steel Structure
Engineered with a heavy-duty A-frame made from high-grade Q235B/Q345B steel, this gantry crane provides outstanding stability and rigidity. The solid, welded construction ensures it can safely handle its maximum rated load with minimal sway, offering a secure lifting platform for your most demanding tasks.
Cost-Effective and Efficient Design
The single-girder design is simpler and more economical than double-girder alternatives, resulting in lower manufacturing, transportation, and installation costs. It provides powerful lifting capabilities that significantly improve workflow and operational efficiency, offering a rapid return on investment.
Versatile Indoor and Outdoor Performance
Designed for adaptability, this crane is equally effective in both indoor and outdoor settings. Its durable, weather-resistant paint finish and protected electrical components ensure reliable performance and a long service life, even when exposed to harsh environmental conditions.
Simple Installation and Low Maintenance
With fewer components than more complex crane systems, the single beam gantry crane is straightforward to assemble and install. This structural simplicity also makes routine inspections and maintenance easy, minimizing downtime and reducing the overall cost of ownership.
Customizable for Your Specific Needs
Weiyuan can engineer this gantry crane to your precise specifications. The span, lifting height, capacity, and hoist type can all be tailored to create a lifting solution that perfectly integrates with your facility’s layout and operational requirements.
Application Scenarios
Manufacturing and Assembly Workshops
Ideal for lifting heavy machinery, large workpieces, and fabricated components on the factory floor. Its wide capacity range makes it suitable for moving items between workstations and supporting various assembly processes.
Precast Concrete and Stone Yards
An excellent solution for handling heavy precast concrete sections, large stone slabs, and granite blocks. Its robust structure is designed to manage the demanding loads common in the construction materials industry.
Warehousing and Logistics Hubs
Perfect for loading and unloading heavy goods from trucks, organizing inventory in outdoor yards, and moving large containers. It provides an efficient lifting solution for logistics and storage operations that handle bulky items.
Steel Distribution and Fabrication Centers
Provides efficient lifting and transport for steel plates, structural beams, and coils in steel service centers and fabrication shops. It helps to streamline operations and improve productivity in metalworking environments.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 0.5 – 20 Ton (Customizable) |
| Span Coverage | 5 – 35m (Customizable) |
| Lifting Height | 3 – 30m (Customizable) |
| Material | High-Strength Q235B / Q345B Steel |
| Work Level | A3/A4/A5 |
| Hoisting Mechanism | CD1/MD1 Electric Wire Rope Hoist or Electric Chain Hoist |
| Crane Travel Speed | 20-30 m/min (Customizable) |
| Control Method | Pendant Control / Wireless Remote Control / Cabin Control |
| Power Supply | 380V/415V/440V, 50/60Hz, 3-Phase or Customized |
| Main Electric Parts | Schneider, Siemens or equivalent reputable brands |
| Operating Temp. | -25°C to +40°C |
Features at a Glance
✓ Wide Capacity Range: Versatile from 0.5 to 20 tons for diverse lifting jobs.
✓ Durable Steel Construction: High-strength A-frame ensures stability and a long service life.
✓ Customizable Dimensions: Span and lifting height are engineered to fit your specific worksite.
✓ Economical Single Girder: Delivers a powerful and cost-effective lifting solution.
✓ Reliable Electric Hoist: Ensures safe, smooth, and efficient lifting operations.
✓ Indoor/Outdoor Versatility: Designed to perform reliably in various work environments.
✓ Flexible Control Options: Available with pendant, wireless remote, or cabin controls for safety and convenience.
FAQ
Q: Is the 0.5-20 ton single girder gantry crane suitable for outdoor use?
A: Yes, it is perfectly suited for outdoor applications. The crane is finished with a specialized anti-corrosion paint, and we offer optional rain covers for the hoist and motors to ensure long-term durability and performance in all weather conditions.
Q: What is the difference between a full gantry and a semi-gantry crane?
A: A full gantry crane, like this model, runs on two legs along rails on the ground, creating a completely independent structure. A semi-gantry crane has one leg on a ground rail while the other side runs on an elevated runway attached to a building, which is useful for saving floor space on one side of the workspace.
Q: Can the crane’s span and lifting height be customized?
A: Absolutely. Weiyuan specializes in creating custom-engineered solutions. We will design the crane’s span and lifting height to precisely match your facility’s dimensions and specific operational needs, ensuring a perfect fit for your workspace.
Q: What kind of foundation is required for this gantry crane?
A: This gantry crane runs on steel rails that must be installed on a solid, level concrete foundation. The foundation needs to be engineered to adequately support the combined weight of the crane and its maximum rated load. We can provide detailed foundation drawings to guide your civil engineering work.
Q: How does Weiyuan guarantee the quality and safety of its gantry cranes?
A: With nearly 40 years of manufacturing experience, Weiyuan operates under a strict ISO-certified quality control system. Every crane is engineered by professionals, fabricated with certified steel, and undergoes a full load test before leaving our factory. We provide a complete quality and test report to ensure it meets all safety and performance standards.
