Weiyuan European-Type Double Girder Crane
Product Overview
The Weiyuan European-Type Double Girder Crane represents the pinnacle of modern industrial lifting solutions, engineered for heavy-duty applications that demand precision, efficiency, and reliability. This high-performance crane integrates advanced European design principles, featuring a lightweight, modular structure, low-headroom hoist trolley, and standard Variable Frequency Drives (VFDs) on all movements. Designed for capacities ranging from 5 to 100 tons, it provides superior strength and stability for wide spans and high lifting heights. The Weiyuan European-Type Double Girder Crane is the premium choice for advanced manufacturing, power generation, automotive plants, and heavy fabrication shops seeking a smart, safe, and cost-effective lifting system.
Product Advantages
Advanced Lightweight and Modular Design
Using Finite Element Method (FEM) analysis, the crane’s double-girder structure is optimized for maximum strength with minimum deadweight. This reduces wheel loads on the runway beams and building structure, often leading to significant savings in construction costs. The modular design simplifies transport, installation, and maintenance.
Superior Performance with Standard VFD Control
This high-performance crane is equipped with VFDs for hoisting, trolley travel, and crane travel as a standard feature. This provides exceptionally smooth, stepless speed control, which minimizes load swing, eliminates shock loading, and allows for precise and gentle positioning of heavy and valuable loads, enhancing both safety and productivity.
Optimized Lifting Height and Space Utilization
The compact, low-headroom design of the European-style hoist trolley maximizes the effective lifting height. By running on top of the double girders, it provides unparalleled vertical clearance, making it an ideal industrial lifting solution for facilities with height restrictions or those needing to lift oversized components.
High Efficiency and Energy Savings
The combination of a lightweight structure and high-efficiency motors with VFD control ensures that the Weiyuan crane consumes significantly less energy than conventional cranes. This not only reduces operational costs over the crane’s lifespan but also supports green manufacturing initiatives by lowering your carbon footprint.
Enhanced Durability and Low Maintenance
Engineered for A5-A7 heavy-duty service, this crane features hardened gear motors, high-quality electrical components from world-leading brands like Schneider and Siemens, and robust construction. These features ensure exceptional reliability, a long service life, and minimal maintenance requirements, maximizing your operational uptime.
Application Scenarios
Heavy Manufacturing and Assembly
This crane is the perfect industrial lifting solution for assembling large machinery, turbines, and aerospace components. Its precision VFD control allows for the exact alignment and placement of heavy parts, streamlining complex assembly processes.
Automotive Industry
Ideal for stamping plants and assembly lines, the Weiyuan crane safely and efficiently handles heavy dies, vehicle frames, and engine blocks. The smooth, gentle movement protects expensive tooling and components from damage.
Power Generation Plants
Essential for maintenance operations in power facilities, this high-performance crane is used for lifting and positioning heavy generators, turbines, and transformers with the utmost safety and precision, ensuring minimal downtime during critical service periods.
Steel and Paper Mills
Built to withstand harsh industrial environments, the crane is perfectly suited for handling heavy steel coils, paper rolls, and scrap metal. Its robust design and reliable performance ensure continuous operation in demanding, high-cycle applications.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 5 Ton – 100 Ton (Customizable) |
| Crane Span | 10.5m – 35.5m (Customizable) |
| Lifting Height | Up to 40m (Customizable) |
| Crane Type | European-Type Double Girder Crane |
| Work Level | A5 – A7 (Heavy to Severe Duty) |
| Hoisting Mechanism | European Low-Headroom Hoist Trolley |
| Lifting Speed | VFD Stepless Control (e.g., 0.8/5 m/min) |
| Travel Speed | VFD Stepless Control (e.g., 2-20 m/min) |
| Control Method | Wireless Remote Control (Standard), Cabin Control (Optional) |
| Power Supply | 380V/415V/440V, 50/60Hz, 3-Phase or Customized |
| Main Electric Parts | Schneider, Siemens, ABB, or equivalent reputable brands |
| Protection Class | IP55 for motors, IP65 for electric cabinet |
Features at a Glance
✓ Advanced European Design: Lightweight, modular, and highly efficient.
✓ Heavy-Duty Capacities: From 5t to 100t for serious industrial lifting.
✓ Standard VFD on All Axes: For superior control, precision, and safety.
✓ Maximized Lifting Height: Low-headroom trolley design for optimal space use.
✓ Energy-Efficient System: Reduces operating costs and supports green initiatives.
✓ Premium Components: Ensures long life, high reliability, and low maintenance.
✓ Comprehensive Safety Features: Overload protection, anti-sway, and redundant limits included.
FAQ
Q: What are the main benefits of a Weiyuan European-Type Double Girder Crane over a traditional one?
A: The Weiyuan European-Type crane is a more advanced industrial lifting solution. It is lighter, more compact, and more energy-efficient. It comes with standard VFD control for smoother and more precise operation, has a lower headroom for better lifting height, and requires less maintenance, resulting in a lower total cost of ownership.
Q: Why is VFD control so important for a high-performance crane?
A: VFD control provides smooth acceleration and deceleration, which drastically reduces load swing and shock on the crane structure. This allows for faster, safer, and more accurate positioning of loads, which is critical when handling heavy, expensive, or fragile items.
Q: Can this crane reduce my building construction costs?
A: Yes. Because the European design is significantly lighter, it imposes smaller wheel loads on the runway and building columns. This can lead to savings in the amount of steel required for the support structure and the size of the foundations, reducing overall project costs.
Q: Is a cabin required for this type of crane?
A: While a wireless remote is standard and sufficient for many applications, a cabin is highly recommended for cranes with very long spans, high travel speeds, or those operating in outdoor or harsh environments. The cabin provides the operator with a protected, climate-controlled workspace with an excellent view of the operation.
Q: How does Weiyuan ensure the quality of its European-Type cranes?
A: Weiyuan combines nearly 40 years of manufacturing excellence with leading European crane technology. Every crane is engineered by our expert team, manufactured under strict ISO quality controls using certified materials, and equipped with world-class components. We perform comprehensive performance and load testing on every crane before shipment to guarantee it meets the highest international standards for safety and reliability.
