Bridge Construction RTG Crane
Product Overview
The Bridge Construction RTG (Rubber Tire Gantry) Crane is a specialized heavy-duty lifting solution engineered for the demands of precast concrete factories and bridge construction sites. With an exceptionally wide lifting capacity ranging from 20 tons to 2,000 tons, this crane is designed to lift, transport, and position massive precast concrete elements like beams, segments, and blocks. Its robust structure and advanced mobility make it an indispensable piece of equipment for modern infrastructure projects, ensuring efficiency and safety in handling oversized loads.
Product Advantages
- Massive Lifting Capacity: Capable of handling loads from 20 to 2,000 tons, accommodating the heaviest precast concrete components.
- Fully Customizable: Key parameters including lifting capacity, height (5m to 80m), and span (5m to 50m) can be tailored to specific project requirements.
- Advanced Mobility: Features oil cylinder-driven steering with a wide steering angle and optional 360-degree steering for superior maneuverability on complex job sites.
- Durable and Versatile: Built with a strong gantry structure and equipped with radial engineering tires or explosion-proof solid tires for reliable performance in demanding environments.
- Comprehensive Structure: Comprises a gantry structure, girder, crane traveling system, power and electrical systems, operator cabin, and specialized lifting system with a spreader for secure handling.
Application Scenarios
- Precast Concrete Yards: Transporting and stacking finished concrete beams from the fabrication area to storage locations.
- Bridge Construction Sites: Lifting precast beams, sections, and segments from transport vehicles to their final installation positions.
- Segmental Bridge Assembly: Precisely lifting, aligning, and splicing prefabricated bridge segments during the construction process.
- Material Handling: Moving other large construction materials, such as steel reinforcement frames and formwork, within the prefabrication yard.
Product Specifications and Dimensions
| Parameter | Details |
|---|---|
| Lifting Capacity | 20 tons to 2,000 tons (customizable) |
| Lifting Height | 5m to 80m (customizable) |
| Span | 5m to 50m (customizable) |
| Tire Type | Radial engineering tires or explosion-proof solid tires |
| Steering Mechanism | Oil cylinder steering (-5° to 950° angle) or 360° motor-driven steering |
| Primary Components | Gantry structure, girder, traveling system, power system, electrical system, cab, lifting system, spreader |
Features at a Glance
- Heavy-Load Specialist: Engineered specifically for lifting extremely heavy precast concrete bridge components.
- Custom-Built for Projects: Each crane is designed and manufactured to meet unique site and load specifications.
- Superior Maneuverability: Advanced steering systems allow for straight, oblique, and 360-degree movements.
- Robust and Reliable: Constructed for durability and consistent performance on demanding construction sites.
- Multi-Functional Use: Lifts a variety of precast shapes, including box-type segments, U-shape beams, T-shape beams, and I-shape beams.
FAQ
1. What is the maximum lifting capacity of the Bridge Construction RTG Crane?
The crane offers a maximum lifting capacity of up to 2,000 tons, with lower capacity models starting at 20 tons. Customization is available to meet specific needs.
2. Can this crane operate on uneven ground?
The RTG crane is designed for stable operation on prepared surfaces typical of precast yards and construction sites. The robust tire system provides excellent mobility.
3. What types of precast elements can this crane handle?
It is designed to handle various precast concrete elements, including box-type segments, U-shape beams, T-shape beams, I-shape beams, and other large blocks.
4. Is the crane’s size customizable?
Yes, the lifting height and span are fully customizable. The lifting height can range from 5m to 80m, and the span from 5m to 50m, to fit your operational space.
5. What steering options are available?
The crane comes with oil cylinder-driven steering for standard and oblique movements. An optional motor-driven gear mechanism is available for full 360-degree steering capabilities.
