Indoor Single Girder Gantry Crane 5 Ton | Workshop Optimized, Compact, CE-Compliant
Product Overview
The 5-Ton Indoor Single Girder Gantry Crane is a highly efficient and space-saving lifting solution designed specifically for workshop and warehouse environments. This crane operates on ground-level rails, providing powerful lifting capability without needing to be supported by the building’s structure. Featuring a compact single girder design and fully motorized travel, it offers smooth and precise movement of heavy loads within a dedicated area. It is the perfect choice for facilities that require a reliable, fixed-path lifting system but lack the structural support for a conventional overhead crane.
Product Advantages
- Optimized for Indoor Use: With a compact footprint and efficient design, this gantry crane is ideal for maximizing lifting capability in workshops, factories, and warehouses with limited space.
- Cost-Effective Installation: As a ground-based system, it completely avoids the need for costly building modifications, runway columns, or foundation reinforcements, making it a highly economical choice.
- Efficient and Safe Operation: Fully motorized travel on the hoist, trolley, and crane allows for effortless, precise handling of 5-ton loads via a simple pendant or wireless remote, enhancing both productivity and operator safety.
- Dedicated Workflow Path: The rail-mounted design provides a fixed, reliable path for repetitive lifting tasks, making it perfect for production lines, assembly bays, and dedicated work cells.
- Durable and Reliable: Built with high-strength steel and equipped with trusted industrial components, this crane is engineered for consistent, low-maintenance performance in daily indoor operations.
Application Scenarios
- Manufacturing Workshops: An excellent solution for moving raw materials, work-in-progress, and heavy components between workstations or along an assembly line.
- Warehouse and Storage: Perfect for lifting heavy pallets, dies, and inventory in areas not serviced by a forklift or overhead crane, especially along a main aisle.
- Machine Shops: Provides dedicated lifting for loading and unloading heavy workpieces from CNC machines, lathes, and other equipment.
- Maintenance Bays: Safely and efficiently lifts heavy engines, motors, and machinery parts for service, repair, and assembly tasks within a fixed bay.
- Loading Docks: Ideal for moving heavy goods between a loading area and an indoor staging zone along a predetermined path.
Product Specifications
| Parameter | Specification |
|---|---|
| Rated Capacity | 5 Ton (Other capacities 1–20t available) |
| Span | 5 m to 25 m (Customized to your workshop bay) |
| Max. Lifting Height | 3 m to 12 m (Customized for indoor ceiling height) |
| Work Duty | A3–A4 (Light to Medium Duty) |
| Lifting Speed | 4–8 m/min (Two-speed on hoist) |
| Trolley Traveling Speed | 2–20 m/min (Two-speed or VFD) |
| Crane Traveling Speed | 10–40 m/min (Two-speed or VFD) |
| Hoist Type | Electric Wire Rope Hoist or Electric Chain Hoist |
| Hoist Motor | Dual-speed conical rotor brake motor |
| Travel Motors | “Three-in-one” soft start or VFD-controlled gear motors |
| Control Methods | Pendant Control (Standard), Wireless Remote Control (Optional) |
| Power Supply | 3-Phase 380V/400V/415V/440V, 50/60Hz |
| Control Voltage | 24V / 36V / 48V (Safe control voltage) |
| Electrical Components | Schneider, Siemens, or equivalent brand |
| Safety Devices | Overload limiter, emergency stop, travel limit switches, rail clamps |
| Working Temperature | -20°C to +40°C |
| Protection Class | IP54 |
| Paint/Finish | Industrial anti-corrosion primer and durable topcoat |
| Steel Grade | Q235B / Q355B Carbon Structural Steel |
| Wheel/End Carriage | Forged steel wheels for rail travel |
| Rail Size (typical) | P24, P38 (Recommended for the application) |
| Braking | Electromagnetic disc brakes for all motors |
| Limit Switches | Included for hoisting, cross travel, and long travel |
| Documentation | Certificate of Conformity, Test Reports, CE/ISO Certificates |
| Warranty | 1 Year |
| Lead Time | 25–40 days (negotiable for specific configurations) |
Features at a Glance
- 5-ton capacity optimized for indoor workshop and warehouse use.
- Space-saving single girder design with a compact footprint.
- Fully motorized operation for efficient and safe load handling.
- Cost-effective solution that operates on ground rails, not building structures.
- CE-compliant design, fully customizable to your facility’s dimensions.
