Mobile Gantry Crane 5 Ton | Portable, Adjustable, CE-Compliant
Product Overview
The 5-Ton Mobile Gantry Crane is a heavy-duty yet highly portable lifting solution designed for ultimate flexibility in workshops, warehouses, and job sites. This crane features a robust A-frame structure mounted on durable, heavy-duty wheels, allowing it to be easily moved to wherever lifting is required. It requires no permanent installation or building modifications, making it a cost-effective and versatile alternative to fixed cranes. With options for adjustable height, manual push, or motorized travel, this 5-ton gantry crane can be configured to meet your specific material handling needs.
Product Advantages
- Exceptional Mobility: Equipped with smooth-rolling, lockable polyurethane or rubber wheels, the crane can be easily maneuvered around obstacles and positioned precisely over loads, both indoors and outdoors.
- Cost-Effective and Independent: Provides powerful 5-ton lifting capability without the high cost and structural requirements of a permanent overhead crane system. It operates independently of the building structure.
- Adjustable for Versatility: Many models feature adjustable height and span, allowing the crane to fit under overhead obstructions, pass through doorways, and adapt to various lifting scenarios and workspaces.
- Simple Assembly and Disassembly: The straightforward, bolted-steel design allows for quick setup and breakdown, making it ideal for transport between job sites or for storage when not in use.
- Safe and Controlled Lifting: Paired with a reliable electric hoist, this gantry provides secure and efficient lifting. The locking wheels and sturdy frame ensure a stable base during operation.
Application Scenarios
- Maintenance and Repair Shops: Perfect for lifting heavy engines, machinery components, and industrial equipment for service and repair tasks.
- Fabrication and Welding Shops: Easily move heavy workpieces, dies, and fabricated sections between different workstations without tying up a forklift.
- Loading and Unloading: A flexible solution for lifting heavy items from trucks or moving materials in areas not accessible by other lifting equipment.
- Outdoor Use: Ideal for construction sites, rental fleets, and outdoor yards where a temporary but powerful lifting solution is needed.
- Die and Mold Handling: Safely and precisely lift and position heavy molds and dies into presses and machinery.
Product Specifications
| Parameter | Specification |
|---|---|
| Rated Capacity | 5 Ton (Other capacities 0.5–10t available) |
| Span | 3 m to 12 m (Customized to your workspace) |
| Max. Lifting Height | 3 m to 9 m (Adjustable height models available) |
| Work Duty | A3–A4 (Light to Medium Duty) |
| Lifting Speed | 4–8 m/min (Two-speed on hoist) |
| Trolley Traveling Speed | Manual push trolley or 2–20 m/min (Electric) |
| Crane Traveling Speed | Manual push or 5–20 m/min (Electric motorized option) |
| Hoist Type | Electric Chain Hoist or compact Electric Wire Rope Hoist |
| Hoist Motor | Standard hoist motor with electromagnetic brake |
| Travel Motors | Optional gear motors for powered travel |
| Control Methods | Pendant Control for hoist; Manual push for gantry travel |
| Power Supply | Single Phase 220V or 3-Phase 380V/400V/415V/440V, 50/60Hz |
| Control Voltage | 24V / 36V / 48V (Safe control voltage) |
| Electrical Components | Schneider, Siemens, or equivalent brand |
| Safety Devices | Overload limiter (optional), emergency stop on pendant |
| Working Temperature | -20°C to +40°C |
| Protection Class | IP54 |
| Paint/Finish | Industrial safety yellow primer and durable topcoat |
| Steel Grade | Q235B / Q355B Carbon Structural Steel |
| Wheel/End Carriage | Heavy-duty rubber or polyurethane wheels with swivel locks and brakes |
| Rail Size (typical) | N/A (Operates on flat floor) |
| Braking | Hoist motor brake; Manual locking brakes on all four wheels |
| Limit Switches | Hoisting up/down limit switches included on hoist |
| Documentation | Certificate of Conformity, Operating Manuals, CE/ISO Certificates |
| Warranty | 1 Year |
| Lead Time | 15–25 days (negotiable for specific configurations) |
Features at a Glance
- Powerful 5-ton lifting capacity in a portable design.
- Easily movable on heavy-duty, lockable wheels for indoor/outdoor use.
- Optional adjustable height for maximum versatility.
- Available in manual push or motorized travel configurations.
- CE-compliant, cost-effective, and requires no permanent installation.
FAQ
1. What’s the information should I provide when inquiry?
More details or drawings, better. A: Lift capacity B: Crane arm length C: lift height: hook travel distance D: What material to lift E: power source or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods: A: pendent controller with push buttons .B: remote control with push buttons. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. What about warranty time ?
Use within the standard for the next 12 months.
5. How can we install the crane? Our senior engineer can be your side to do the installation guide service and training.
6. May I visit your factory?
Of course. We can pick you up at train station, high-speed rail station or airport, and book hotel for you.
