Gantry crane

Product Overview

The Weiyuan Portable Electric Gantry Crane offers an exceptional combination of power and mobility, providing a robust 10-ton lifting capacity in a flexible, adjustable frame. This crane is engineered for workshops, warehouses, and job sites where a permanent overhead crane is not feasible or required. Its key features include adjustable height and easy mobility, allowing you to move and position heavy loads with precision and safety. Whether you’re involved in equipment maintenance, die handling, or material loading, this portable gantry crane is the ultimate solution for enhancing efficiency and reducing manual labor.

Product Advantages

Maximum Portability and Flexibility
Designed for ultimate convenience, this gantry crane is equipped with heavy-duty casters, allowing it to be easily moved to any location within your facility. Its portability eliminates the need for fixed lifting equipment, providing a versatile solution that adapts to your changing workflow.

Adjustable Height for Versatile Applications
The crane features an adjustable height mechanism, enabling you to modify the lifting height to suit various tasks and overcome overhead clearance limitations. This adaptability makes it perfect for a wide range of applications, from low-ceiling workshops to open-air sites.

Heavy-Duty 10-Ton Capacity
Despite its portable design, this crane boasts a powerful 10-ton lifting capacity. It is constructed from high-strength steel to ensure stability and safety when handling heavy loads, making it a reliable workhorse for demanding lifting jobs.

Simple Assembly and Operation
Engineered for user-friendliness, the crane has a simple structure that is easy to assemble and disassemble. This makes it ideal for projects that require transportation between different sites. Operation is straightforward with an intuitive pendant or optional wireless remote control.

Cost-Effective Lifting Solution
The Weiyuan portable gantry crane offers a highly economical alternative to permanent crane installations. It requires no building modifications or costly foundation work, providing a powerful lifting solution with a lower initial investment and greater operational flexibility.

Application Scenarios

Maintenance and Repair Shops
Perfect for lifting heavy engines, transmissions, and industrial machinery components. Its mobility allows technicians to position the crane directly over the equipment being serviced, improving safety and efficiency.

Manufacturing and Assembly
Ideal for moving heavy sub-assemblies, molds, and dies within a production facility. It can serve multiple workstations without the need for a fixed overhead system, streamlining the manufacturing process.

Warehouse and Loading Docks
An excellent tool for loading and unloading heavy or awkwardly shaped items from trucks and flatbeds. It can be moved to wherever it’s needed most, providing lifting power in areas not serviced by forklifts or fixed cranes.

Construction and Project Sites
Provides a temporary and powerful lifting solution on job sites for moving materials, tools, and structural components. Its easy assembly and transport make it perfect for short-term projects.

Product Specifications and Dimensions

Specification	Parameters
Lifting Capacity	10 Ton (Customizable from 0.5-10t)
Span	2-10m (Customizable)
Lifting Height	1-6m (Adjustable, Customizable)
Work Level	A3, A4
Lifting Mechanism	Electric Chain Hoist / Electric Wire Rope Hoist
Travel Mechanism	Heavy-Duty Casters (Polyurethane, Motorized optional)
Control Method	Pendant Control / Wireless Remote Control
Power Supply	220V/380V/400V/415V, 50/60Hz, 3-Phase or Customized
Main Electric Parts	Schneider or equivalent reputable brands
Material	High-Strength Carbon Steel, Aluminum Alloy options available
Operating Temp.	-20°C to +40°C

Features at a Glance

✓ 10-Ton Lifting Capacity: Strong performance for a wide range of heavy loads.

✓ Portable and Mobile: Easily move the crane around your workspace on durable casters.

✓ Adjustable Height: Adaptable for different lifting requirements and ceiling heights.

✓ Simple and Quick Assembly: Can be set up or taken down with ease for transport.

✓ Robust Steel Frame: Ensures stability and safety during all lifting operations.

✓ Flexible Control Options: Comes with a pendant control, with a wireless remote available.

✓ Economical and Versatile: No need for permanent installation or building modifications.

FAQ

Q: How is the portable gantry crane moved?

A: The standard model is equipped with heavy-duty polyurethane casters that allow it to be pushed manually into position. For higher capacities or more frequent movement, we offer motorized travel as an option, which allows the crane to be driven via the control pendant.

Q: Is the height difficult to adjust?

A: No, the height is designed for easy adjustment. Depending on the model, it can be adjusted using a manual winch system or an electric drive. This allows you to set the ideal height for each specific lifting task safely and efficiently.

Q: Can this 10-ton portable crane be used on uneven surfaces?

A: For maximum safety and stability, portable gantry cranes should be used on a hard, flat, and level surface. Using the crane on a sloped or uneven surface is not recommended as it can compromise its stability.

Q: What type of hoist is supplied with the crane?

A: We can equip the crane with either an electric chain hoist or an electric wire rope hoist, depending on your preference and application. An electric chain hoist is generally more compact, while a wire rope hoist may offer faster lifting speeds. We can help you choose the best option.

Q: How does Weiyuan guarantee the quality and safety of its portable cranes?

A: As a manufacturer with nearly 40 years of expertise, Weiyuan builds every crane under a strict ISO-compliant quality control system. Each portable gantry crane is made from high-quality steel and undergoes rigorous load testing and inspection before shipment to ensure it meets our high standards for safety, durability, and performance.
