Weiyuan MH Box Type Gantry Crane for Material Lifting | Versatile, Robust, Efficient
Product Overview
The Weiyuan MH Box Type Single Girder Gantry Crane is a fundamental and highly versatile solution for a wide range of material lifting applications. Engineered for reliability and efficiency, this crane features a strong, single box-girder design supported by A-frame legs that travel on ground-level rails. This makes it an ideal choice for both indoor and outdoor settings where an overhead crane system is not practical. Whether you are lifting raw materials, finished products, or heavy components, the Weiyuan MH gantry crane provides a safe, dependable, and cost-effective lifting capability.
Product Advantages
- Robust Box-Girder Structure: The Weiyuan-built box girder offers superior torsional rigidity and durability compared to standard I-beams, ensuring stable and reliable lifting performance over a long service life.
- Adaptable to Any Environment: Perfectly suited for a variety of material lifting tasks, this crane can be configured for outdoor use with weatherproof features or for indoor use in workshops and warehouses.
- Space-Efficient Operation: Because it runs on the ground and is self-supporting, it provides lifting coverage without requiring building support columns, making it perfect for open yards and existing buildings.
- User-Friendly and Safe: With simple controls, such as a pendant or wireless remote, operators can manage loads with precision and from a safe distance, enhancing workplace safety.
- Economical and Low Maintenance: The crane’s straightforward design, sourced directly from the Weiyuan factory, ensures an affordable initial investment and low ongoing maintenance costs.
Application Scenarios
- Manufacturing and Assembly: Lifting and moving heavy parts, sub-assemblies, and finished goods along a production line or within a factory.
- Material Storage Yards: An essential tool for organizing and handling heavy materials like steel coils, stone slabs, pipes, and precast concrete elements.
- Logistics and Warehousing: Facilitates the loading and unloading of heavy freight from trucks and is useful for general material handling in warehouse areas.
- Repair and Maintenance Shops: Lifting heavy equipment, engines, and machinery components for service and repair operations.
- General Construction: Provides on-site lifting capability for moving structural materials, equipment, and tools around a job site.
Product Specifications
| Parameter | Specification |
|---|---|
| Brand | Weiyuan |
| Rated Capacity | 3t to 20t (Customizable for your application) |
| Span | Up to 35 m (Customized) |
| Max. Lifting Height | Up to 20 m (Customized) |
| Work Duty | A3–A5 (Light to Medium Duty) |
| Girder Type | Single Box Girder |
| Lifting Speed | Customized (Single, dual, or VFD control available) |
| Trolley Traveling Speed | 20 m/min (Customizable) |
| Crane Traveling Speed | 20 m/min (Customizable) |
| Control Methods | Pendant Control (Standard), Wireless Remote Control (Optional) |
| Power Supply | 3-Phase 380V/400V/415V/440V, 50/60Hz |
| Electrical Components | Schneider, Siemens, or equivalent quality brands |
| Safety Devices | Overload limiter, emergency stop, travel limit switches, buffers |
| Working Temperature | -25°C to +40°C |
| Protection Class | IP54 (Upgraded to IP55 for outdoor use) |
| Steel Grade | Q235B / Q355B Carbon Structural Steel |
| Warranty | 1 Year |
| Lead Time | 20–35 days (Negotiable) |
Features at a Glance
- Versatile Weiyuan MH gantry crane for general material lifting.
- Durable box-girder design for enhanced stability and longevity.
- Ideal for both outdoor yards and indoor workshops.
- Simple, ground-traveling system is easy to install and maintain.
- Fully customizable by Weiyuan to suit your specific lifting application.
FAQ
1. What’s the information should I provide when inquiry?
More details or drawings, better. A: Lift capacity B: Crane arm length C: lift height: hook travel distance D: What material to lift E: power source or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods: A: pendent controller with push buttons .B: remote control with push buttons. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. What about warranty time ?
Use within the standard for the next 12 months.
5. How can we install the crane? Our senior engineer can be your side to do the installation guide service and training.
6. May I visit your factory?
Of course. We can pick you up at train station, high-speed rail station or airport, and book hotel for you.
