Gantry crane
Weiyuan Motor-Driven Portable Gantry Crane | Low Price, Customized, Free Moving
Product Overview
The Weiyuan Motor-Driven Portable Gantry Crane is a versatile and economical lifting solution designed for flexibility and ease of use. This free-moving gantry crane is not fixed to rails, allowing it to be easily repositioned anywhere in your facility on its durable polyurethane wheels. The motor-driven travel feature enables smooth, powered movement with minimal physical effort, enhancing operational efficiency and safety. Offered at a low, factory-direct price, this customized crane from Weiyuan is perfect for workshops, warehouses, and assembly lines where lifting needs vary by location.
Product Advantages
- Low Price, High Value: By offering a customized solution directly from the factory, Weiyuan provides this high-quality portable gantry crane at an exceptionally competitive price point, ensuring a fast return on your investment.
- Motor-Driven Free Movement: The integrated motor drive allows the operator to move the entire crane effortlessly using a simple control, eliminating the strain of manual pushing and enabling precise positioning.
- Ultimate Portability: Equipped with robust, non-marking caster wheels, this crane can be easily moved on any smooth concrete floor, providing lifting capability exactly where you need it, when you need it.
- Customized to Your Needs: Weiyuan can customize the crane’s height, span, and capacity to perfectly suit your specific lifting tasks and facility constraints, providing a tailor-made solution without a high cost.
- Simple and Quick Assembly: The crane features a straightforward, bolt-together design, allowing for quick and easy assembly or disassembly for transport or storage.
Application Scenarios
- Maintenance Workshops: Ideal for lifting engines, transmissions, and heavy components from vehicles or machinery for repair and servicing.
- Manufacturing and Assembly: A perfect tool for moving sub-assemblies, molds, and parts along a production line or between different work cells.
- Warehouse Operations: Useful for lifting heavy items from pallets, positioning goods, and assisting with loading and unloading in areas not covered by a forklift.
- Garages and Small Shops: Provides a safe and powerful lifting solution for small businesses, enabling them to handle heavy materials without investing in a permanent overhead crane.
- Rental Fleets: An excellent, durable, and in-demand product for equipment rental companies serving various light industrial and construction clients.
Product Specifications
| Parameter | Specification |
|---|---|
| Brand | Weiyuan |
| Rated Capacity | 0.5t to 10t (Customizable) |
| Span (Width) | Up to 10 m (Customized to your needs) |
| Lifting Height | Up to 9 m (Customizable, can be fixed or adjustable) |
| Girder Type | Single I-beam or Box Girder |
| Travel | Motor-Driven Electric Travel |
| Wheels | Heavy-duty polyurethane caster wheels (2 fixed, 2 swivel with brakes) |
| Lifting Mechanism | Electric Chain Hoist or Electric Wire Rope Hoist |
| Control Methods | Pendant Control, Wireless Remote Control |
| Power Supply | 3-Phase 380V/400V/415V/440V, 50/60Hz, or as per request |
| Hoisting Speed | Single or Dual Speed |
| Safety Devices | Emergency stop button, overload protection (optional) |
| Steel Grade | Q235B Carbon Structural Steel |
| Warranty | 1 Year |
| Lead Time | 15–25 days (Negotiable) |
Features at a Glance
- Low-price, customizable portable gantry crane from Weiyuan.
- Motor-driven for effortless, free-moving travel across flat surfaces.
- Ideal for versatile lifting in workshops, warehouses, and assembly areas.
- Simple bolt-together design for easy assembly and relocation.
- Available with fixed or adjustable height configurations.
FAQ
1. What’s the information should I provide when inquiry?
More details or drawings, better. A: Lift capacity B: Crane arm length C: lift height: hook travel distance D: What material to lift E: power source or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods: A: pendent controller with push buttons .B: remote control with push buttons. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. What about warranty time ?
Use within the standard for the next 12 months.
5. How can we install the crane? Our senior engineer can be your side to do the installation guide service and training.
6. May I visit your factory?
Of course. We can pick you up at train station, high-speed rail station or airport, and book hotel for you.
