Cantilever crane
Wall Mounted Jib Crane
Product Overview
The Weiyuan Wall Mounted Jib Crane is a highly efficient and space-saving lifting solution, ideal for workshops, assembly lines, and manufacturing facilities. Offered in capacities from 1 to 3 tons, this crane is designed to be mounted directly onto a structurally sound wall or building column, providing a dedicated lifting station without consuming any valuable floor space. Its robust design features a 180-degree rotation, enabling the quick and effortless movement of materials within a semi-circular work area. Paired with a dependable electric hoist, this jib crane is the perfect asset for boosting workflow, increasing productivity, and enhancing safety in localized work zones.
Product Advantages
Zero Floor Space Occupation
By mounting directly to an existing vertical structure, this jib crane keeps the workshop floor completely clear. This is a crucial advantage in busy facilities where floor space is limited, allowing for an unobstructed and safer work environment.
Economical Lifting Solution
This crane is a cost-effective choice because it leverages your building’s existing structure for support, which eliminates the need for a costly foundation or a freestanding column. This leads to lower material costs, simpler and faster installation, and a quicker return on investment.
Improved Localized Efficiency
The crane provides a dedicated lifting resource for a specific workstation, perfect for feeding materials to machines, supporting assembly tasks, or moving items in a localized area. This reduces waiting times for larger overhead cranes and streamlines the overall production process.
Durable and Low-Maintenance Design
Engineered for longevity, the crane features a sturdy steel I-beam boom and a heavy-duty wall bracket. The simple and reliable design requires minimal maintenance, ensuring years of dependable service and a low total cost of ownership.
Smooth and Safe Load Handling
The jib crane is equipped with a high-quality electric chain or wire rope hoist, offering smooth and precise lifting. The 180-degree rotation is fluid and easy to control, either manually or with an optional electric drive, allowing operators to position loads with accuracy and safety.
Application Scenarios
Manufacturing and Assembly Lines
Perfect for lifting and transferring components between adjacent workstations on an assembly line. It provides rapid, repetitive lifting that can significantly accelerate production and reduce manual effort.
Machine Shops and Fabrication
An ideal solution for loading and unloading heavy workpieces, dies, and tooling from CNC machines, lathes, and presses. It empowers a single operator to safely handle heavy items, improving both safety and efficiency.
Warehouse and Packing Stations
Provides an excellent lifting solution for specific zones within a warehouse or near a packing station, especially where floor space is tight and a forklift or larger crane is impractical.
Maintenance and Repair Bays
A vital tool for lifting heavy equipment parts like engines, pumps, and motors in repair workshops. It allows technicians to safely and easily handle heavy components during servicing operations.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 1 Ton, 2 Ton, 3 Ton (Customizable up to 5t) |
| Arm Length (Span) | 2m – 10m (Customizable) |
| Lifting Height | 2m – 10m (Based on installation height) |
| Slewing Angle | 180 Degrees |
| Material | High-Strength Q235B / Q345B Steel |
| Work Level | A3 (Light Duty) |
| Hoisting Mechanism | Electric Chain Hoist or Electric Wire Rope Hoist |
| Slewing Mechanism | Manual Rotation (Standard) / Electric Slewing (Optional) |
| Control Method | Pendant Control / Wireless Remote Control |
| Power Supply | 380V/415V/440V, 50/60Hz, 3-Phase or Customized |
| Main Electric Parts | Schneider, Siemens, or equivalent reputable brands |
| Operating Temp. | -20°C to +40°C |
Features at a Glance
✓ Space-Saving Wall Mount: Frees up valuable floor space for other operations.
✓ Versatile Capacities: Available in 1T, 2T, and 3T for various light-duty tasks.
✓ 180-Degree Work Area: Provides excellent coverage for localized lifting.
✓ Cost-Effective Installation: Utilizes existing building structure, reducing overall cost.
✓ Durable Steel Construction: Ensures a long and reliable service life.
✓ High-Performance Hoist: Provides safe, smooth, and efficient lifting control.
✓ Customizable Solution: Arm length and features can be engineered to your needs.
FAQ
Q: What are the structural requirements for installing a wall-mounted jib crane?
A: Installation requires a structurally sound reinforced concrete wall or a sufficiently strong steel building column. It is mandatory to have a qualified structural engineer verify that the mounting location can safely withstand the forces exerted by the crane at its full rated capacity. We will provide all necessary thrust and pull force data for this analysis.
Q: Should I choose manual or electric rotation?
A: For shorter arm lengths (up to 4-5 meters) and lighter capacities (1-2 tons), manual rotation is typically sufficient and more economical. For longer arms, heavier capacities, or applications that demand frequent or more precise positioning, electric rotation is highly recommended for ease of use and enhanced safety.
Q: Can this jib crane rotate more than 180 degrees?
A: No, the standard wall-mounted design is physically limited to a 180-degree rotation. If your application requires greater rotation (e.g., 270 or 360 degrees), we recommend considering our freestanding, column-mounted jib crane models.
Q: Which is better for this crane: an electric chain hoist or a wire rope hoist?
A: For most wall-mounted jib crane applications up to 3 tons, an electric chain hoist is the preferred choice. It is more compact, offers true vertical lift, and is highly cost-effective. An electric wire rope hoist might be considered if you need a much faster lifting speed or a significantly longer lifting height.
Q: How does Weiyuan ensure the quality and safety of its jib cranes?
A: With nearly 40 years of manufacturing expertise, Weiyuan builds all cranes under a strict ISO-certified quality management system. Each wall-mounted jib crane is designed by our professional engineers, fabricated from certified high-strength steel, and undergoes a full load test before shipment to guarantee it meets our rigorous standards for safety, durability, and performance.
