Fixed Pillar Jib Crane
Product Overview
The Fixed Pillar Jib Crane is a robust material handling solution engineered by Weiyuan, featuring advanced lightweight, modular, and parametric design principles for superior performance in demanding industrial environments. This floor-mounted crane system incorporates cutting-edge hoisting mechanism options including NR model low-headroom electric hoist, NL mode chain electric hoist, or NS model servo electric hoist with exceptional performance capabilities. The crane features sophisticated slewing mechanisms driven by special slewing devices for jib cranes or cycloid pin wheel three-in-one devices, paired with an advanced variable frequency speed regulation control system for precise operational control. Designed for safety, reliability, energy efficiency, and environmental sustainability, this crane represents the pinnacle of fixed pillar jib crane technology.
Product Advantages
Versatile Hoisting Mechanism Options
Offers multiple hoisting configurations including NR model low-headroom electric hoist for space-constrained environments, NL mode chain electric hoist for cost-effective operations, and NS model servo electric hoist for precision control applications requiring exact positioning.
Advanced Modular Design Architecture
Features comprehensive modular construction with 8 drive units compatible with 15 different motor power configurations, enabling flexible customization, simplified maintenance procedures, and reduced operational complexity for enhanced cost-effectiveness.
Dual Slewing System Options
Incorporates either special slewing devices designed specifically for jib cranes or advanced cycloid pin wheel three-in-one devices, providing optimal rotation control and enhanced durability for diverse operational requirements.
Intelligent Variable Frequency Control
Utilizes state-of-the-art variable frequency speed regulation with intelligent manufacturing capabilities, providing precise control, stable operation, and enhanced safety features specifically engineered for smart factory environments.
Silent Operation Technology
Features advanced silent drive systems with active noise cancellation, significantly reducing workshop noise pollution and creating comfortable working environments while meeting stringent industrial noise standards.
Application Scenarios
Manufacturing and Assembly Operations
Ideal for production facilities, assembly lines, and manufacturing processes requiring reliable material handling with 360-degree coverage in specific work areas without requiring runway infrastructure or wall mounting capabilities.
Warehouses and Distribution Centers
Perfect for storage facilities, logistics centers, and distribution operations where standalone lifting capability provides efficient material movement in designated areas while maximizing operational flexibility.
Maintenance and Service Facilities
Excellent for maintenance workshops, service centers, and repair operations where fixed positioning combined with rotational capability provides comprehensive coverage for equipment servicing and component handling.
Construction and Industrial Sites
Designed for construction projects, industrial installations, and infrastructure development where standalone jib crane systems provide targeted lifting solutions without requiring existing structural support.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 0.5t to 10t load range |
| Radius of Gyration | 3m to 15m coverage area |
| Lifting Height | 3m to 30m vertical range |
| Work Level Classification | A5 duty cycle rating |
| Hoisting Options | NR low-headroom, NL chain, NS servo electric hoists |
| Slewing Mechanism | Special slewing device or cycloid pin wheel three-in-one |
| Control System | Variable frequency speed regulation |
| Installation Type | Fixed pillar floor-mounted system |
Features at a Glance
✓ Multiple Hoist Configurations: NR low-headroom, NL chain, and NS servo electric hoist options for diverse applications
✓ Dual Slewing Options: Special jib crane slewing device or cycloid pin wheel three-in-one system for optimal performance
✓ 360-Degree Coverage: Complete rotational capability providing comprehensive workspace coverage from fixed position
✓ Variable Frequency Control: Precise speed regulation with stable operation for accurate load positioning
✓ Comprehensive Safety Systems: Complete protection devices including upper pre-limit, limit switches, and impact-proof mechanisms
✓ Silent Drive Technology: Low noise environmental protection with advanced transmission for workplace comfort
✓ Intelligent Function Suite: Inching movement, dead slow, zero speed hover, and electric anti-sway capabilities
FAQ
Q: What are the advantages of fixed pillar installation over other jib crane types?
A: Fixed pillar installation provides maximum stability, 360-degree rotational coverage, independence from existing structures, and flexibility in placement while offering superior load capacity and operational reliability for demanding applications.
Q: Which slewing mechanism option is best for my application?
A: Special slewing devices for jib cranes offer optimized performance for standard applications, while cycloid pin wheel three-in-one devices provide enhanced precision, reduced maintenance, and superior durability for demanding operational requirements.
Q: How does the variable frequency control system enhance crane performance?
A: Variable frequency speed regulation provides smooth operation, precise control, reduced energy consumption, and enhanced safety through customizable acceleration and deceleration profiles with multiple speed settings for different operational requirements.
Q: What intelligent functions improve operational safety and efficiency?
A: The crane features inching movement for precise positioning, dead slow function for stability, zero speed hover to prevent slip hook, electric anti-sway for accurate handling, and regional load limits for enhanced safety.
Q: Can multiple fixed pillar jib cranes be coordinated for complex lifting operations?
A: Yes, the system supports multi-crane coordination capabilities, allowing multiple fixed pillar jib cranes to work synchronously with position monitoring and speed control for complex lifting operations requiring coordinated movements.
