Wall Mounted Jib Crane
Product Overview
The Wall Mounted Jib Crane is an innovative material handling solution engineered by Weiyuan, featuring advanced lightweight, modular, and parametric design principles for superior performance in space-constrained environments. This wall-mounted crane system incorporates cutting-edge hoisting mechanism options including NR model low-headroom electric hoist, NL mode chain electric hoist, or NS model servo electric hoist with exceptional performance capabilities. The crane features a sophisticated cycloid pin wheel reducer device for the slewing mechanism and an advanced variable frequency speed regulation control system for precise operational control. Designed for safety, reliability, energy efficiency, and environmental sustainability, this crane represents the next generation of wall-mounted lifting solutions.
Product Advantages
Versatile Hoisting Technologies
Offers multiple hoisting mechanism configurations including NR model low-headroom electric hoist for space-constrained applications, NL mode chain electric hoist for cost-effective solutions, and NS model servo electric hoist for precision control applications.
Advanced Modular Architecture
Features comprehensive modular design with 8 drive units compatible with 15 different motor power configurations, enabling flexible customization, simplified maintenance procedures, and reduced operational complexity for enhanced cost-effectiveness.
Intelligent Variable Frequency Control
Incorporates state-of-the-art variable frequency speed regulation with intelligent manufacturing capabilities, providing precise control, stable operation, and enhanced safety features specifically engineered for smart factory environments.
Space-Efficient Wall Mounting
Engineered for wall-mounted installation, maximizing floor space utilization while providing comprehensive lifting coverage without requiring floor-mounted supports or interfering with ground-level operations and workflow.
Silent Operation Technology
Features advanced silent drive systems with active noise cancellation, significantly reducing workshop noise pollution and creating comfortable working environments while meeting stringent industrial noise standards.
Application Scenarios
Manufacturing and Production Facilities
Ideal for manufacturing plants, assembly operations, and production facilities where wall-mounted crane systems provide efficient material handling without occupying valuable floor space or interfering with production workflows.
Warehouses and Storage Operations
Perfect for storage facilities, distribution centers, and logistics operations requiring efficient material movement along building perimeters while maximizing central floor space for storage and operational activities.
Maintenance and Service Centers
Excellent for maintenance workshops, service facilities, and repair operations where wall-mounted lifting capability provides precise positioning for equipment servicing and component handling in linear work areas.
Construction and Building Sites
Designed for construction applications, building projects, and infrastructure development where wall-mounted crane systems provide targeted lifting solutions along building structures and perimeter areas.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 0.5t to 10t load range |
| Radius of Gyration | 3m to 15m coverage area |
| Lifting Height | 3m to 30m vertical range |
| Work Level Classification | A5 duty cycle rating |
| Hoisting Options | NR low-headroom, NL chain, NS servo electric hoists |
| Slewing Mechanism | Cycloid pin wheel reducer device |
| Control System | Variable frequency speed regulation |
| Mounting Type | Wall-mounted installation system |
Features at a Glance
✓ Multiple Hoist Configurations: NR low-headroom, NL chain, and NS servo electric hoist options for diverse applications
✓ Advanced Slewing System: Cycloid pin wheel reducer device for smooth and precise rotation control
✓ Variable Frequency Control: Precise speed regulation with stable operation for accurate load positioning
✓ Comprehensive Safety Systems: Complete protection devices including upper pre-limit, limit switches, and impact-proof mechanisms
✓ Silent Drive Technology: Low noise environmental protection with advanced transmission for workplace comfort
✓ Intelligent Function Suite: Inching movement, dead slow, zero speed hover, and electric anti-sway capabilities
✓ Wireless Connectivity: Optional integration with Crane Industrial Internet Platform for full lifecycle management
FAQ
Q: What are the advantages of wall-mounted installation over floor-mounted cranes?
A: Wall-mounted installation maximizes floor space utilization, eliminates the need for floor-mounted supports, reduces installation complexity, and provides targeted lifting coverage along building perimeters without interfering with ground operations.
Q: Which hoisting mechanism is best suited for my application?
A: NR low-headroom electric hoists are ideal for space-constrained environments, NL chain electric hoists offer cost-effective solutions for standard applications, and NS servo electric hoists provide precision control for demanding positioning requirements.
Q: How does the cycloid pin wheel reducer enhance slewing performance?
A: The cycloid pin wheel reducer provides smooth rotation, high torque transmission, reduced backlash, and enhanced durability, resulting in precise slewing control and extended operational life with minimal maintenance requirements.
Q: What intelligent functions improve operational safety and efficiency?
A: The crane features inching movement for precise positioning, dead slow function for stability, zero speed hover to prevent slip hook, electric anti-sway for accurate handling, and regional load limits for enhanced safety.
Q: Can the crane be integrated with existing facility management systems?
A: Yes, optional wireless modules enable connection to the Crane Industrial Internet Platform, providing full lifecycle management, remote monitoring, and seamless integration with smart factory systems and facility management platforms.
