Weiyuan BZ Type Floor-Fixed Jib Crane
Product Overview
The Weiyuan BZ Type Floor-Fixed Jib Crane is a powerful and versatile freestanding lifting solution engineered for modern industrial efficiency. With an expansive capacity range from 500kg to 10 tons, this crane is designed to serve as a robust lifting point in workshops, manufacturing plants, and assembly areas. It features a heavy-duty pillar anchored securely to a concrete foundation, supporting a cantilever arm that rotates up to 360 degrees. Paired with a high-performance electric hoist, this floor-mounted jib crane offers a localized, high-efficiency lifting system that enhances productivity and safety.
Product Advantages
- Broad Lifting Capacity: Offering a wide spectrum of capacities from 0.5T to 10T, you can select the perfect crane to match your specific lifting requirements, from light-duty component handling to heavy-duty industrial lifting.
- Flexible Rotational Coverage: With customizable slewing angles of 180, 270, or a full 360 degrees, the crane provides comprehensive circular coverage, allowing a single unit to service multiple workstations and maximize utility within its radius.
- Independent and Space-Saving: As a self-supporting structure, it operates independently of your building’s support columns. This freestanding design allows for flexible placement anywhere a solid foundation can be laid, optimizing your floor space.
- Increased Productivity: The crane dramatically reduces manual labor and streamlines workflow. Its smooth rotation and reliable electric hoist enable a single operator to move heavy loads quickly, safely, and with minimal effort, boosting overall efficiency.
- Economical and Low Maintenance: Characterized by its simple structure, the BZ Type jib crane is an economical investment compared to larger overhead crane systems. It is easy to install, requires minimal maintenance, and is built for a long, reliable service life.
Application Scenarios
- Manufacturing and Assembly Lines: Perfect for lifting and positioning heavy parts, sub-assemblies, and finished goods along a production line.
- Machine Shops and Fabrication Centers: An indispensable tool for loading heavy materials onto CNC machines, changing dies, and moving large weldments.
- Warehouses and Storage Yards: Ideal for lifting heavy items in specific areas not covered by a main crane, such as loading docks or dedicated work cells.
- Maintenance and Repair Facilities: Provides essential lifting support for removing and installing heavy components like engines, pumps, and motors.
- Ports and Terminals: Suitable for smaller-scale, localized lifting tasks, helping to move supplies and equipment with precision and safety.
Product Specifications
| Parameter | Details |
|---|---|
| Rated Lifting Capacity | 0.5T, 1T, 2T, 3T, 5T, 10T (Customizable) |
| Arm Length (Effective Radius) | 2m to 12m (Customizable) |
| Lifting Height | 1m to 10m (Customizable) |
| Slewing Angle | 180°, 270°, or 360° |
| Slewing Mechanism | Motorized or Manual Push |
| Lifting Mechanism | Electric Wire Rope Hoist or Electric Chain Hoist |
| Control Method | Pendant Control / Wireless Remote Control |
| Working Duty | A3 (Light to Medium Duty) |
| Power Supply | 3-phase AC, 380V/50Hz (or as required) |
| Core Components | Pillar, Jib Arm, Slewing Drive, Electric Hoist, Motor |
| Certification | ISO, CE Certified |
Features at a Glance
- Heavy-Duty Steel Pillar: A thick, high-strength steel column provides a rigid and stable foundation for safe lifting operations.
- Robust I-Beam Arm: The cantilever arm is engineered to handle rated loads with minimal deflection, ensuring stability and safety.
- Smooth Slewing System: Features a high-quality slewing bearing for effortless rotation, available in both manual and motorized options for precise control.
- High-Performance Electric Hoist: Paired with a reliable CD/MD wire rope hoist or an electric chain hoist for efficient and safe vertical lifting.
- Integrated Safety Features: Equipped with upper and lower limit switches, an emergency stop button, and overload protection to ensure secure operation.
FAQ
1. What kind of foundation is needed for a floor-fixed jib crane?
A pillar jib crane requires a specially designed reinforced concrete foundation to safely anchor the crane and counteract the lifting forces. The foundation’s dimensions and reinforcement will depend on the crane’s capacity, height, and arm length, and it should be designed by a qualified civil engineer.
2. Should I choose manual or motorized rotation for my jib crane?
Manual rotation is a cost-effective choice for lighter capacities (up to 2 tons) and shorter arm lengths. For heavier loads, longer arms, or high-frequency use, motorized rotation provides superior control, precision, and operator ergonomics.
3. What is the difference between a jib crane and a gantry crane?
A jib crane consists of a single pillar and a rotating arm, providing circular lifting coverage in a fixed area. A gantry crane has two legs that travel on rails or wheels, covering a rectangular area and is typically used to span the width of a workshop.
4. Can this BZ-type jib crane be used outdoors?
Yes, it can be manufactured for outdoor use. This requires special protective measures, including weatherproof paint, a rain cover for the hoist and motors, and electrical components rated for outdoor exposure.
5. How can I get a price for a customized jib crane?
Simply contact our sales team with your key requirements: desired lifting capacity, required arm length (radius), lifting height, preferred rotation type, and your facility’s power supply details. We will provide a detailed and competitive quotation tailored to your needs.
