Weiyuan Wall-Mounted Slewing Jib Crane
Product Overview
The Weiyuan Wall-Mounted Slewing Jib Crane is an innovative, space-saving lifting solution designed to maximize your production area. By mounting directly onto an existing wall or building column, this crane provides robust lifting power without consuming any valuable floor space. It features a slewing jib arm that swings through a 180-degree arc, creating a highly efficient semi-circular work zone. Paired with a responsive electric hoist and an intuitive remote control, this crane is the perfect choice for workshops, assembly lines, and warehouses looking to enhance workflow in a specific area.
Product Advantages
Zero Floor Footprint
Free up your factory floor. This crane mounts to your existing structural supports, leaving the ground clear for machinery, materials, and personnel traffic. It’s the ideal way to add lifting capacity to a crowded workspace without causing obstruction.
Enhanced Safety with Remote Control
Operate with greater freedom and a better field of vision. The included wireless remote control allows the operator to stand clear of the load, choosing the safest vantage point to manage lifting and slewing operations. This significantly improves workplace safety over pendant-controlled alternatives.
Cost-Effective and Efficient Installation
Leverage your existing infrastructure. By using a wall or pillar for support, this jib crane eliminates the cost and time associated with pouring a large concrete foundation for a freestanding crane. It’s a highly economical way to create a dedicated lifting station.
Targeted Workstation Productivity
Create a powerhouse of efficiency in a focused area. This crane is perfect for serving one or two adjacent workstations, enabling a single operator to lift, position, and transfer materials quickly and precisely, reducing idle time and boosting output.
Customizable for Your Structure
Weiyuan engineers each wall-mounted jib crane to fit your facility. We customize the arm length, lifting capacity, and mounting bracket specifications to ensure a secure and perfect fit for your specific wall or column structure, providing a truly integrated lifting system.
Application Scenarios
- Assembly and Fabrication Bays: Ideal for lifting and positioning components along a wall-side assembly line or within a specific welding bay.
- Machine Shops: Provides dedicated lifting for loading and unloading workpieces and tools from lathes, mills, and other machines positioned against a wall.
- Warehouse Loading Docks: Facilitates the movement of goods between loading bays and staging areas, improving the speed and safety of shipping and receiving operations.
- Garages and Maintenance Workshops: An excellent tool for lifting engines and heavy parts over a designated service bay, keeping the surrounding floor area clear.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 0.5t, 1t, 2t, 3t, 5t (Customizable) |
| Span (Arm Length) | 4m – 8m (Customizable) |
| Lifting Height | Determined by mounting height |
| Work Level | A3 |
| Slewing (Rotation) Angle | 180° (standard, others available) |
| Slewing Method | Manual or Motorized |
| Hoist Type | Electric Wire Rope Hoist or Chain Hoist |
| Control Method | Wireless Remote Control (standard) / Pendant Control |
| Power Supply | 380V/415V/440V, 50/60Hz, 3-Phase |
| Mounting Type | Wall or Column Bracket Mount |
Features at a Glance
✓ Wall-Mounted Design: Saves 100% of your floor space.
✓ Wireless Remote Control: Enhances operator safety and flexibility.
✓ 180-Degree Slewing Arc: Perfectly covers a semi-circular work area.
✓ Economical Installation: Uses existing building structures for support.
✓ Durable and Reliable: Built with high-strength steel for a long service life.
✓ Fully Customizable: Tailored to your capacity, span, and mounting needs.
FAQ
Q: What kind of wall is required to support this jib crane?
A: The crane must be mounted to a structurally sound, reinforced concrete wall or a sufficiently strong steel building column. It cannot be attached to a standard brick or block wall. Weiyuan will provide the load data and mounting requirements for your structural engineer to verify the suitability of your chosen location.
Q: What is the main advantage of a wireless remote over a pendant control?
A: Safety and visibility. A wireless remote frees the operator from being tethered to the hoist, allowing them to move to the best possible position to view the load and surrounding area, avoiding pinch points and potential hazards.
Q: Can the slewing (rotation) be motorized?
A: Yes. While manual slewing is standard and cost-effective for lighter loads and shorter arms, we offer motorized slewing as an option. It is recommended for capacities over 2 tons or for long arm lengths to ensure smooth, effortless rotation.
Q: How is the lifting height determined for a wall-mounted crane?
A: The effective lifting height is determined by the height at which you mount the crane on the wall, minus the height of the hoist and trolley assembly. We can help you calculate the optimal mounting height to achieve your desired hook height.
Q: How do I get a quote for a 1-ton wall-mounted jib crane?
A: For a precise quote, please contact us with your key requirements: 1) 1-ton capacity, 2) Desired arm length (span), 3) The required hook height from the floor, and 4) Information about the wall or column you plan to mount it on. We will provide a comprehensive solution for your review.
