Wireless Control Wall Mounted Jib Crane
Product Overview
The Weiyuan Wall Mounted Jib Crane with Wireless Control offers a modern, efficient, and exceptionally safe lifting solution for workshops, assembly stations, and manufacturing facilities. Available in 1 and 2-ton capacities, this crane mounts directly to a building’s structural wall or column, freeing up valuable floor space while providing dedicated lifting power. The inclusion of a responsive wireless remote control allows the operator to manage lifting and movement from a safe distance with optimal visibility. This combination of a space-saving design and advanced control makes it an ideal choice for enhancing workflow, improving safety, and boosting productivity in localized work areas.
Product Advantages
Enhanced Safety with Wireless Control
The industrial-grade wireless remote control allows the operator to stand clear of the load, providing better visibility of the lifting operation and eliminating the hazard of being tethered by a pendant cable. This significantly improves workplace safety and allows for more precise load positioning.
Maximizes Usable Floor Space
By mounting directly onto an existing wall or building column, this jib crane requires zero floor space. This is a critical benefit in busy workshops or production areas, ensuring the floor remains clear for traffic, materials, and other operations.
Cost-Effective and Simple Installation
This crane is a highly economical lifting solution because it utilizes your existing building structure for support. This eliminates the expense and time required for pouring a new foundation, making installation simpler, faster, and more affordable.
Increased Operational Efficiency
Providing a dedicated lifting resource for a specific workstation reduces downtime spent waiting for an overhead crane. It is perfect for repetitive tasks like machine loading or assembly, streamlining the workflow and increasing overall productivity.
Durable and Reliable Construction
Engineered from high-strength steel, the jib arm and wall bracket are built for durability and a long service life. The simple, robust design, paired with a high-quality electric hoist, ensures reliable performance with minimal maintenance requirements.
Application Scenarios
Manufacturing and Assembly Lines
Ideal for lifting components and sub-assemblies at individual workstations. The wireless control allows operators to precisely align parts without being restricted by a control cable, speeding up the assembly process.
Machine Shops and CNC Centers
Perfect for loading and unloading heavy workpieces, molds, and dies from machinery. The operator can manage the lift from the safest vantage point, improving efficiency and reducing the risk of accidents.
Packing and Shipping Areas
Provides an excellent solution for lifting and positioning goods onto pallets or into crates near a loading dock. The space-saving design keeps the area uncluttered and safe for other activities.
Maintenance and Repair Workshops
An indispensable tool for lifting heavy parts such as engines and transmissions. The wireless remote gives technicians the freedom to move around the object they are working on while maintaining full control of the lift.
Product Specifications and Dimensions
| Specification | Parameters |
|---|---|
| Lifting Capacity | 1 Ton, 2 Ton (Customizable up to 5t) |
| Arm Length (Span) | 2m – 10m (Customizable) |
| Lifting Height | Up to 10m (Determined by installation height) |
| Slewing Angle | 180 Degrees |
| Material | High-Strength Q235B / Q345B Steel |
| Work Level | A3 (Light Duty) |
| Hoisting Mechanism | Electric Chain Hoist or Electric Wire Rope Hoist |
| Slewing Mechanism | Manual Rotation (Standard) / Electric Slewing (Optional) |
| Control Method | Wireless Remote Control (Standard), Pendant Control (Backup) |
| Power Supply | 380V/415V/440V, 50/60Hz, 3-Phase or Customized |
| Main Electric Parts | Schneider, Siemens, or equivalent reputable brands |
| Operating Temp. | -20°C to +40°C |
Features at a Glance
✓ Wireless Remote Control: For enhanced operator safety and visibility.
✓ Space-Saving Wall Mount: Keeps your workshop floor completely clear.
✓ Versatile Capacities: Available in 1T and 2T for a wide range of tasks.
✓ 180-Degree Work Area: Provides excellent coverage for localized lifting jobs.
✓ Economical Solution: Uses existing structure, reducing installation costs.
✓ Durable Steel Construction: Ensures a long and reliable service life with low maintenance.
✓ Customizable Arm Length: Engineered to fit your specific workspace requirements.
FAQ
Q: What are the main benefits of wireless control over a standard pendant control?
A: Wireless control offers superior safety and flexibility. It allows the operator to move freely and choose the best position to view the lift, away from the load and potential hazards. It also eliminates tangled or damaged pendant cables, which are a common maintenance issue.
Q: What structural support is needed to install this jib crane?
A: The crane must be mounted to a structurally sound, reinforced concrete wall or a substantial steel building column. A qualified structural engineer must verify that the mounting surface can safely handle the thrust and pull forces exerted by the crane at its maximum capacity. We provide all necessary load data for this critical analysis.
Q: Can the rotation of the jib arm also be controlled wirelessly?
A: Yes. If you select the optional electric slewing (rotation) mechanism, its movement can be integrated into the wireless remote control, providing powered control over both lifting and rotation for a fully remote-operated system.
Q: Is a backup control method included?
A: Yes, we typically supply a plug-in pendant control as a backup or for maintenance purposes, ensuring you can always operate the crane even if the wireless remote’s batteries are depleted or it is being serviced.
Q: How does Weiyuan ensure the quality and safety of its wireless jib cranes?
A: With nearly 40 years of manufacturing excellence, Weiyuan produces all equipment under a strict ISO-certified quality control system. Each jib crane is fabricated from certified steel, equipped with reliable electronics, and undergoes a comprehensive load test before shipment to guarantee it meets our rigorous standards for safety, durability, and performance.
