KBK light crane system
Compact European Modular Hoisting Unit for Maximized Vertical Hook Clearance
1. Product Overview
The Weiyuan DHR Low-Headroom Electric Wire Rope Hoist integrates modern European modular architecture with an ultra-compact trolley geometry. Specially engineered for single-girder overhead cranes and monorail systems, this low-headroom configuration places the hoist frame alongside the main beam rather than beneath it. This design significantly maximizes effective lifting height in low-ceiling plant environments, optimizing space utilization and lowering overall building construction costs.
2. Key Advantages & Technical Highlights
- Maximized Lifting Clearance: Ultra-compact trolley profile minimizes the distance between the hook and the runway flange, gaining critical hook travel height.
- 3-in-1 Integrated Drive Assembly: High-efficiency motor, hardened helical gearbox, and electromagnetic disc brake integrated into a maintenance-friendly, zero-backlash power unit.
- Large-Diameter Rope Drum: Extends steel wire rope service life, reduces fleet angles, and minimizes horizontal hook drift during vertical lifting.
- Variable Frequency Inverter Control: Standard stepless or dual-speed travel profiles guarantee smooth acceleration, precise load positioning, and zero load swaying.
3. Technical Specifications
| Specification Parameter | Standard Value / Range |
|---|---|
| Rated Lifting Capacity | 1.6 Ton – 12.5 Ton |
| Lifting Height | 6m / 9m / 12m / 18m / 24m |
| Lifting Speed | 0.8 / 5.0 m/min (Dual Speed) or VFD Stepless |
| Trolley Travel Speed | 2 – 20 m/min (Variable Frequency Control) |
| Wire Rope Grade | 1960 N/mm² High-Tensile Galvanized Steel Core Rope |
| Duty Rating / FEM | FEM 2m / 3m (ISO A5 / A6) |
| Protection & Insulation | IP55 Enclosure / Class H Motor Insulation |
4. Typical Application Scenarios
- Low-clearance machinery manufacturing bays and precision assembly workshops
- Automotive stamping plant toolrooms and mold maintenance centers
- Logistics packaging facilities and commercial warehouse storage aisles
- HVAC equipment manufacturing plants and pump station maintenance bays
FAQ
1. What’s the information should I provide when inquiry?
More details or drawings, better. A: Lift capacity B: Crane arm length C: lift height: hook travel distance D: What material to lift E: power source or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods: A: pendent controller with push buttons .B: remote control with push buttons. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. What about warranty time ?
12 months.
5. How can we install the crane? Our senior engineer can be your side to do the installation guide service and training.
6. May I visit your factory?
Of course. We can pick you up at train station, high-speed rail station or airport, and book hotel for you.
