KBK light crane system
Versatile Stationary Hoisting & Winch Drive for Heavy Engineering Applications
1. Product Overview
Designed for stationary mounting on structural frames, concrete foundations, or specialized crane trolleys, the Weiyuan DHR Foot-Mounted Fixed Wire Rope Hoist Unit serves as an exceptionally rigid lifting mechanism. Built around the proven DHR modular drive architecture, this base-mounted hoist provides high lifting force, excellent rope capacity, and flexible mounting orientations for industrial winch and stationary hoisting operations.
2. Key Advantages & Technical Highlights
- Rigid Foot-Mounted Housing: Precision-machined base mounting feet allow secure, vibration-free bolting to floor foundations or crane frames.
- Flexible Cable Reeling Outlets: Multi-directional rope reeving options enable top, bottom, or lateral wire rope payout to match custom site layouts.
- Heavy-Duty Planetary Gearbox: Hardened helical and planetary gear transmission ensures maximum mechanical efficiency and silent operation.
- Modular Component Accessibility: Separately accessible motor, brake, and drum components streamline routine maintenance and inspection.
3. Technical Specifications
| Specification Parameter | Standard Value / Range |
|---|---|
| Rated Lifting Capacity | 3 Ton – 25 Ton |
| Lifting Height | 12m / 18m / 24m / 30m / 36m (High-capacity drum options) |
| Lifting Speed | 0.8 / 5.0 m/min (Dual Speed) or Inverter Control |
| Wire Rope Construction | 1960 N/mm² Galvanized Anti-Rotation Wire Rope |
| Duty Rating / FEM | FEM 2m / 3m (ISO A5 / A6) |
| Motor Enclosure Rating | IP55 (IP65 optional) |
| Control Options | Remote Radio Control / Wall-Mounted Control Panel |
4. Typical Application Scenarios
- Mining shaft vertical extraction winches and underground equipment hoists
- Dam gate hoisting mechanisms and water conservancy sluice lifting
- Heavy industrial elevator systems and freight lift winches
- Shipyard slipway winches and dry dock vessel haulage systems
FAQ
1. What’s the information should I provide when inquiry?
More details or drawings, better. A: Lift capacity B: Crane arm length C: lift height: hook travel distance D: What material to lift E: power source or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods: A: pendent controller with push buttons .B: remote control with push buttons. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. What about warranty time ?
12 months.
5. How can we install the crane? Our senior engineer can be your side to do the installation guide service and training.
6. May I visit your factory?
Of course. We can pick you up at train station, high-speed rail station or airport, and book hotel for you.
